>visionsystems.de/VScom 200E PCIex (4502.html)   Features PCI Express x1 2x RS232 16C950 (128 Byte FIFO) 921 kbps PCI Plug and Play Drivers for Windows 2000 to 7/2008R2 Extra bracket for Low Profile cases       VScom 200E PCIex Quick Link: | Features | More Pictures | Overview | Hardware Specifications | High Performance Features | Operating Systems | Ordering Information | Download | |   More Pictures Klick on the thumbnails to enlarge them … >Back to top         Overview The VScom 200E PCIex is an add-on card for PCI Express, providing two serial ports. These high speed serial ports with their 128 byte long FIFO are best for high speed communication, even in heavy loaded systems. Many unique features reduce the system load. They also allow very unusual speed settings such as 500.000bps. The extra bracket allows to place the card in Low Profile cases. Read the News Article…   Hardware Specifications Ports 2x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI) UART 2x 16C950 (128 Byte FIFO) Address Plug and Play Interrupts PCI Plug and Play, only one interrupt per card Speed max. 921 kbps Bus interface PCI Express x1 Connectors 1x DB25, adapter cable 2 x DB9 male Low Profile Extra bracket for alternative mounting Temperature 0°C - 55°C >Back to top         High Performance Features FIFO adjustable FIFO length, 1 up to 128 Bytes separate adjustable Rx and Tx Handshake RTS / CTS DTR / DSR Xon / Xoff all handshake automatic on Chip Speed 1 bps up to 921 kbps unusual Baudrates possible Multiplication factor for legacy applications Access high speed access via Memory UART UART emulation of 8250 up to 16850 >Back to top         Operating Systems Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions Linux Kernel 2.6.35 and up: built-in support >Back to top         Ordering Information Art.No 4502 Product Name VScom 200E PCIex Packing list VScom 200E PCIex card Adapter cable 2 Ports RS232 DSUB 9 male Bracket for Low Profile cases CD, English documentation >Back to top       Download   Windows 7, Server 2008 R2 x86 + x64 Editions  (Release 3.3.0.15 (February 19 2010)) Windows XP to Vista Server 2003 to 2008 x86 Edition  (Release 3.3.0.12 (January 7 2009)) Windows XP to Vista Server 2003 to 2008 x64 Edition  (Release 3.3.0.12 (January 7 2009)) Board manual  (Manual for PCIex E-series boards, Edition February 2010) >Back to top
